47
Part Detail
n
°
1 Stator, complete
2 Welded stator frame
3 Interpole coil
5 Shunt field coil
10 Armature complete
11 Armature core
12 Commutator
13 Rotor coils
15 Slot wedge
16 Balancing disk D-end
17 Balancing disk ND-end
18 Internal cooling fan for cooling form IC01
20 Brush device, assembly
21 Brush-holder
22 Screw for brush-rocher
23 Washer
25 Set of brushes
26 Brush-rocker
30 Bearing end-shield, D-end
31 Inner bearing cover, D-end
32 Ball-bearing D-end
33 Roller bearing D-end
34 Spacing pin
35 Outer bearing cover, D-end
36 Screw for end-shield
37 Lubricating nipple
39 Lubrication duct
40 Bearing end-shield ND-end
41 Inner bearing cover ND-end
42 Ball-bearing ND-end
43 Washer
44 Locking ring
45 Outer bearing cover, ND-end
46 Screw for end-shield
50 End-shield, D-end
51 End-shield - ND-end
52 Screw
53 Washer
54 Gasket
55 Flange
56 Screw
57 Washer
58 Nut
59 Air deflector
60 Terminal box
Nomenclature DMP
Explanation of details
Part Detail
n
°
61 Terminal box housing
63 Terminal board
64 Covering plate for terminal box
65 Gasket for terminal box covering plate
66 Front for terminal box cover
67 Gasket for terminal box housing & covers
68 Screw for terminal box housing & covers
69 Screw for terminal board
70 Inspection cover
71 Louvers for motor in horizontal mounting IC 06
72 Louvers for motor in vertical mounting IC 06
73 Gasket for louvers & inspection covers
74 Cover used when terminal box sidely mounted
75 Gasket for cover (item 74)
76 Key on the free shaft end
79 Eye bolt
80 Screw for louvers & inspection covers
90 Tachogenerator
92 Stub shaft
93 Bowex coupling for standard tachogenerator
type REO 444 N or R
94 Rotex coupling for standard tachogenerator REO
95 Thomas coupling for standard tachogenerator
type REO 444 N or R
96 Mechanical coupling Thomas for reinforced
tachogenerator or pulse generator
97 Intermediate housing
98 Inspection cover
99 Standard tachogenerator type REO 444,
1 collector
100 Standard tachogenerator type REO 444,
2 collectors
101 Reinforced tachogenerator type REO 444,
1 collector
102 Fixing screw for intermediate housing
& for tachogenerator
103 Screw for coupling
105 Gasket
110 Complete motor fan (IC06)
111 Fan unit
112 Fan AC motor
113 Louver for fan unit
114 Gasket
115 Complete filter assembly
116 Filter cartridge
117 Cover for filter cartridge
120 Pressure relay
