Appendix A – CoE Object Dictionary 123
Note: The Transparent and ABB Drives command values cannot
be changed with an SDO write service.
Drive parameter access via CoE objects
Drive parameters can be accessed via objects 0x4001…0x4063.
The 8 least significant bits of the object index correspond to the
drive parameter group and the sub-index is the drive parameter
index.
Examples:
• Object 0x400A:02 = drive par. 10.02
• Object 0x4033:0F = drive par. 51.15
4001 0 Group 1 U8 R Drive parameter
group 1
1 Parameter
1.01
Drive parameter 1.01 Drv
2 Parameter
1.02
Drive parameter 1.02 Drv
…… … … … … …
……… ………… …
4063 Group 99 U8 R Drive parameter
group 99
1 Parameter
99.01
Drive parameter
99.01
Drv
…… … … … … …
Index Subindex
Bit 15…8 7…0 8…0
Value 0x40 Drive par. group (hex) Drive par. index (hex)
Index SI Name Type Ac-
cess
PM Information NVS
