Manual
motor protectors
Low Voltage Products & Systems 5.5
ABB Inc. • 888-385-1221 • www.abb-control.com AC 1000 - 11/03
PS1-...
S1- M2
S1- M2
PS1-...
UA1-...
SA1
HKF1-11
SK1-...
HK1-...
HK1-...
HK1-...
Busbars for Type MS116
Description
Catalog List
number price
for 2 devices without auxiliary contacts PS1-2-0 $ 24
for 3 devices without auxiliary contacts PS1-3-0 30
for 4 devices without auxiliary contacts PS1-4-0 36
for 5 devices without auxiliary contacts PS1-5-0 42
for 2 devices with 1 auxiliary contact PS1-2-1 24
for 3 devices with 1 auxiliary contact PS1-3-1 30
for 4 devices with 1 auxiliary contact PS1-4-1 36
for 5 devices with 1 auxiliary contact PS1-5-1 42
for 2 devices with 2 auxiliary contacts PS1-2-2 24
for 3 devices with 2 auxiliary contacts PS1-3-2 30
for 4 devices with 2 auxiliary contacts PS1-4-2 36
for 5 devices with 2 auxiliary contacts PS1-5-2 42
Type MS116
Accessories
Power feed terminal blocks for Type MS116
Description
Catalog List
number price
for 4 AWG wire S1-M1
$ 24
for busbar S1-M2
Door mounting hardware for for Type MS116 1
Description
Catalog List
number price
Shaft coupler MSMN $ 15
NEMA 1, 3R, 12 Black selector handle OHB2AJ 30
NEMA 1, 3R, 12 Red, yellow selector handle OHY2AJ 30
4.1” length shaft OXS5X105 4
7.1” length shaft OXS5X180 6
OHB2AJ
1 Must have shaft coupler, handle and shaft for through-the-door operation.
S1-M1 S1-M2
PS1-2-1
Discount schedule MA – Manual motor protectors
Discount schedule H6 – Handles, shafts & accessories
Busbar for direct mounting of contactors
Description
Catalog List
number price
B6/B7 BEA7/116 $ 12
A9/A12/A16 BEA16/116 13.50
A26 BEA26/116 15
PS1-4-1
