ABB PMA User Manual

41-973.5R
24
Type PM Line of Relays For Pilot Wire Monitoring
And Transferred Tripping
Figure 20: Internal Schematic of the Type PMG-13 Relay in the FT-32 case -
120 volts, 60 hertz supply – for two or three-terminal lines.
Figure 21: PMG-13 Relay with Ground Alarm and Remote Trip - two-terminal
lines with Telephone Relay Output. FT-32 case
Sub 4 184A513
Sub 11 3490A59
