Softstarters Type PSE18...PSE370 Installation and commissioning manual 1SFC132057M0201 47 Chapter 6
6.1.2.1 LED status indicators
The LED status indicators work as in table 6.1:
Table 6.1
LED Color Description
Ready Green • Off: when control supply voltage U
s
is off or uncon-
nected.
• Flashing light when control supply voltage U
s
is On
and operational voltage U
e
is Off.
• Steady light when control supply voltage U
s
is On,
and operational voltage U
e
is On.
Run Green • Off when the motor not is running.
• Flashing light when softstarter is controlling opera-
tional voltage U
e
during start or stop ramp.
• Steady light when full operational voltage U
e
is on
at Top of Ramp.
Protection Yellow • Off: when the softstarter has not tripped on any
protection
• Steady light on protection when reset is not pos-
sible.
• Flashing light on protection when reset is possible.
Fault Red • Off: when the softstarter has not tripped on any
fault
• Steady light on fault when reset is not possible.
• Flashing light on fault when reset is possible.
When fault or protection LED is activated, the LCD display will show the actual
fault or protection as an event code. See table 10.1.
