Function IEC 61850 IEC 60617 IEC-ANSI
Multi-purpose protection, instance 1
1)
MAPGAPC1 MAP (1) MAP (1)
Multi-purpose protection, instance 2
1)
MAPGAPC2 MAP (2) MAP (2)
Multi-purpose protection, instance 3
1)
MAPGAPC3 MAP (3) MAP (3)
Control
Circuit-breaker control CBXCBR1 I <-> O CB I <-> O CB
Disconnector position indication,
instance 1
DCSXSWI1 I <-> O DC (1) I <-> O DC (1)
Disconnector position indication,
instance 2
DCSXSWI2 I <-> O DC (2) I <-> O DC (2)
Disconnector position indication,
instance 3
DCSXSWI3 I <-> O DC (3) I <-> O DC (3)
Earthing switch indication ESSXSWI1 I <-> O ES I <-> O ES
Emergency startup ESMGAPC1 ESTART ESTART
Condition monitoring
Circuit-breaker condition monitoring SSCBR1 CBCM CBCM
Trip circuit supervision, instance 1 TCSSCBR1 TCS (1) TCM (1)
Trip circuit supervision, instance 2 TCSSCBR2 TCS (2) TCM (2)
Current circuit supervision CCRDIF1 MCS 3I MCS 3I
Fuse failure supervision SEQRFUF1 FUSEF 60
Runtime counter for machines and
devices
MDSOPT1 OPTS OPTM
Measurement
Disturbance recorder RDRE1 - -
Three-phase current measurement,
instance 1
CMMXU1 3I 3I
Sequence current measurement CSMSQI1 I1, I2, I0 I1, I2, I0
Residual current measurement,
instance 1
RESCMMXU1 Io In
Three-phase voltage measurement VMMXU1 3U 3U
Residual voltage measurement RESVMMXU1 Uo Vn
Sequence voltage measurement VSMSQI1 U1, U2, U0 U1, U2, U0
Three-phase power and energy
measurement, including power factor
PEMMXU1 P, E P, E
RTD/mA measurement XRGGIO130 X130 (RTD) X130 (RTD)
Frequency measurement FMMXU1 f f
1) Multi-purpose protection is used for, for example, RTD/mA based protection.
Section 1 1MRS756882 B
Introduction
8 REM615
