The corresponding parameter values are "On" and "Off".
• IED input/output messages and monitored data names are shown in Courier
font, for example:
When the function starts, the START output is set to TRUE.
1.4.3 Functions, codes and symbols
Table 1: REM615 Functions, codes and symbols
Function IEC 61850 IEC 60617 IEC-ANSI
Protection
Three-phase non-directional
overcurrent protection, low stage,
instance 1
PHLPTOC1 3I> (1) 51P-1 (1)
Three-phase non-directional
overcurrent protection, instantaneous
stage, instance 1
PHIPTOC1 3I>>> (1) 50P/51P (1)
Non-directional earth-fault protection,
low stage, instance 1
EFLPTOC1 Io> (1) 51N-1 (1)
Non-directional earth-fault protection,
high stage, instance 1
EFHPTOC1 Io>> (1) 51N-2 (1)
Directional earth-fault protection, low
stage, instance 1
DEFLPDEF1 Io> -> (1) 67N-1 (1)
Three-phase undervoltage protection,
instance 1
PHPTUV1 3U< (1) 27 (1)
Positive-sequence undervoltage
protection, instance 1
PSPTUV1 U1< (1) 47U+ (1)
Negative-sequence overvoltage
protection, instance 1
NSPTOV1 U2> (1) 47O- (1)
Frequency protection, instance 1 FRPFRQ1 f>/f<,df/dt (1) 81 (1)
Frequency protection, instance 2 FRPFRQ2 f>/f<,df/dt (2) 81 (2)
Negative-sequence overcurrent
protection for motors, instance 1
MNSPTOC1 I2>M (1) 46M (1)
Negative-sequence overcurrent
protection for motors, instance 2
MNSPTOC2 I2>M (2) 46M (2)
Loss of load supervision LOFLPTUC1 3I< 37
Motor load jam protection JAMPTOC1 Ist> 51LR
Motor start-up supervision STTPMSU1 Is2t n< 49,66,48,51LR
Phase reversal protection PREVPTOC1 I2>> 46R
Thermal overload protection for motors MPTTR1 3Ith>M 49M
Circuit breaker failure protection CCBRBRF1 3I>/Io>BF 51BF/51NBF
Master trip, instance 1 TRPPTRC1 Master Trip (1) 94/86 (1)
Master trip, instance 2 TRPPTRC2 Master Trip (2) 94/86 (2)
Arc protection, instance 1 ARCSARC1 ARC (1) 50L/50NL (1)
Arc protection, instance 2 ARCSARC2 ARC (2) 50L/50NL (2)
Arc protection, instance 3 ARCSARC3 ARC (3) 50L/50NL (3)
Table continues on next page
1MRS756882 B Section 1
Introduction
REM615 7
Point List Manual

ABB RELION REM615 Specifications

General

Type	Feeder Protection and Control
Rated Frequency	50/60 Hz
Operating Temperature	-25 °C to +55 °C
Input Voltage	100-240 V AC/DC
Mounting	Panel mounting
Communication Protocols	IEC 61850, Modbus, DNP3
Protection Functions	Overcurrent, earth fault
Dimensions	177 mm
Rated Voltage	100…240 V AC/DC
