1MAC302441-MB A Section 2
IEC 60870-5-101/104 data mappings
RER620 13
Point List Manual
VMMXU1.PPV.phsCA.cVal.mag.f 8058 "VA,VB,VC:phase CA amplitude" Yes
VMMXU1.PPV.phsCA.instCVal.ang.f 8059 "VA,VB,VC:phase CA angle" Yes
VMMXU2.PhV.phsA.cVal.ang.f 8061 "VA,VB,VC(2):phase A angle" Yes
VMMXU2.PhV.phsA.cVal.mag.f 8062 "VA,VB,VC(2):phase A amplitude" Yes
VMMXU2.PhV.phsB.cVal.ang.f 8063 "VA,VB,VC(2):phase B angle" Yes
VMMXU2.PhV.phsB.cVal.mag.f 8064 "VA,VB,VC(2):phase B amplitude" Yes
VMMXU2.PhV.phsC.cVal.ang.f 8065 "VA,VB,VC(2):phase C angle" Yes
VMMXU2.PhV.phsC.cVal.mag.f 8066 "VA,VB,VC(2):phase C amplitude" Yes
VMMXU2.PPV.phsAB.cVal.mag.f 8067 "VA,VB,VC(2):phase AB amplitude" Yes
VMMXU2.PPV.phsAB.instCVal.ang.f 8068 "VA,VB,VC(2):phase AB angle" Yes
VMMXU2.PPV.phsBC.cVal.mag.f 8070 "VA,VB,VC(2):phase BC amplitude" Yes
VMMXU2.PPV.phsBC.instCVal.ang.f 8071 "VA,VB,VC(2):phase BC angle" Yes
VMMXU2.PPV.phsCA.cVal.mag.f 8073 "VA,VB,VC(2):phase CA amplitude" Yes
VMMXU2.PPV.phsCA.instCVal.ang.f 8074 "VA,VB,VC(2):phase CA angle" Yes
VSMSQI1.SeqV.c1.cVal.mag.f 8076 "V1,V2,V0:amplitude" Yes
VSMSQI1.SeqV.c1.instCVal.ang.f 8078 "V1,V2,V0:angle" Yes
VSMSQI1.SeqV.c2.cVal.mag.f 8081 "V1,V2,V0:amplitude" Yes
VSMSQI1.SeqV.c2.instCVal.ang.f 8083 "V1,V2,V0:angle" Yes
VSMSQI1.SeqV.c3.cVal.mag.f 8087 "V1,V2,V0:amplitude" Yes
VSMSQI1.SeqV.c3.instCVal.ang.f 8088 "V1,V2,V0:angle" Yes
VSMSQI2.SeqV.c1.cVal.mag.f 8091 "V1,V2,V0(2):amplitude" Yes
VSMSQI2.SeqV.c1.instCVal.ang.f 8093 "V1,V2,V0(2):angle" Yes
VSMSQI2.SeqV.c2.cVal.mag.f 8097 "V1,V2,V0(2):amplitude" Yes
VSMSQI2.SeqV.c2.instCVal.ang.f 8098 "V1,V2,V0(2):angle" Yes
VSMSQI2.SeqV.c3.cVal.mag.f 8102 "V1,V2,V0(2):amplitude" Yes
VSMSQI2.SeqV.c3.instCVal.ang.f 8103 "V1,V2,V0(2):angle" Yes
LLN0.Beh.stVal 10000 LLN0:Beh status Yes
LLN0.LocRem.stVal 10002 LLN0:LocRem status Yes
LPHD1.NumCmpChg.stVal 10003 LPHD1:NumCmpChg status Yes
LPHD1.NumPwrUp.stVal 10004 LPHD1:NumPwrUp status Yes
LPHD1.PhyHealth.stVal 10005 LPHD1:PhyHealth status Yes
LPHD1.PhyHealth1.stVal 10006 LPHD1:PhyHealth1 status Yes
LPHD1.PhyHealth2.stVal 10007 LPHD1:PhyHealth2 status Yes
LPHD1.WacTrg.stVal 10008 LPHD1:WacTrg status Yes
LPHD1.WrmStr.stVal 10009 LPHD1:WrmStr status Yes
DNZSRDIR1.OpChrAng.mag.f 10105 32N:OpChrAng magnitude Yes
DPSRDIR1.OpChrAng.mag.f 10106 32P:OpChrAng magnitude Yes
DRFLO1.FltLoopX.mag.f 10108 FLO:FltLoopX magnitude Yes
DRFLO1.FltZ.mag.f 10109 FLO:FltZ magnitude Yes
NSPTOV2.StrDur.mag.f 10110 47-2:StrDur magnitude Yes
RDRE1.FltNum.stVal 10111 DFR:FltNum status Yes
No events 61850 Path IOA Disabled Description Multiplier Interrogation
