ABB VD4 Series Instruction Manual

20 ABB Power Distribution
Designation Item Auxiliary Ident no.
no. voltage (order code)
Auxiliary switch S1 GCE7002397R0122
(with clamp-type terminal) S3 GCE7002397R0121
S4 GCE7002397R0122
S5 GCE7002397R01..
1)
Auxiliary switch on blocking magnet S2 GCE7003022P0101
Auxiliary switch for fault annunciation S7 GCE0905121P0100
1st shunt release OFF Y2 GCE7004590P01..
2)
2nd shunt release OFF Y9 GCE7004590P01..
2)
Shunt release ON Y3 GCE7004590P01..
2)
Blocking magnet Y1 GCE9478103P01..
2)
Undervoltage release Y4 GCE9371466R01..
2)
with spring mechanism
Delayed undervoltage release Y4 GCE9371466R01..
2)
with spring mechanism
Indirect overcurrent release with intermediate Y7 GCE9371466R0112
current transformer and spring mechanism
Intermediate current transformer for GCE9476148R0100
indirect overcurrent release
Magnet holder, complete GCE7000880R0111
(with integrated rectifiers V1, V2, V3, V9)
Series rectifier V4/V7 GCE7004046R0101
Charging motor M0 DC 24 V GCE0940084P0101
DC 48 V GCE0940084P0103
DC 60 V GCE0940084P0104
DC/AC 110 V GCE0940084P0105
DC 125 V GCE0940084P0105
DC/AC 220/240 V GCE0940084P0106
Push-on sleeve 4.8-2.5 DIN 46247 Page 2
for push-on blade 0.8 thick
(for additional external connections)
(with gearing)
1)
Quote contact arrangement
2)
State the type of release and voltage
7.5.2 Auxiliary materials Ident no.
(order code)
Lubricant:
• Isoflex Topas NB 52 GCE0007249P0100
Halogen-free cleanser:
• Rivolta BWR 210 GCE0007707P0100
(for general cleaning)
Observe the relevant ABB instruction manual BA1002/E GCEA901002P0102
• Cold cleanser (Kaltreiniger) 716 GCE0007706P0100
(use for conductive components, insulating-material
components and for heavy contamination)
Observe the relevant ABB instruction manual BA 1006/E GCEA901006P0102
