Acer AL1714 User Manual

Technical Specifications
Panel Dimension
Diagonal 431.8mm (17 inch) LCD display
Max. Resolution
1,280 x 1,024/ SXGA
Max. Pixel Up to 16.2M true color
Pixel Span
Horizontal 0.264mm x Vertical 0.264mm
Brightness
370 cd/m
2
Contrast
350 : 1
LC Response Time
14ms
Visual Angle
Horizontal 160° / Vertical 120°
LCD Panel
(Back Light Source)
Effective Display
Horizontal 337.9mm x Vertical 270.3mm
Signal Mode
Simulated video frequency: 0.7 Vpp, 75Ω
(separate SYNC and composite SYNC)
SYNC Frequency
Horizontal 22kHz~82kHz x Vertical 56Hz ~76 Hz
Input Signal
Max. Pixel Clock
135MHz
Input Terminal Image
D-Sub 15 PIN (VESA)
Power Transformer
AC100~240Volts, 60 /50Hz
Power Consumption
51W / Standby 3W
Temperature
5℃ ~ 35℃ (operation)/ -20℃ ~ 55℃ (storage)
Environmental
Conditions
Humidity
20% ~ 80% (operation)/ 20% ~ 85% (storage)
Actual Dimension (W x D x H)
383.9 mm x 390.4 mm x 203.7 mm
Net Weight
3.5 kg
Safety Standard
TCO99 ; UL/CUL; TÜV-GS; CE/LVD; TÜV-ERGO ; CB ; CCC ; B
mark ; FCC-B; VCCI-B ; CE/EMC; C-Tick ; BSMI ; ISO 13406-2
7

Acer AL1714 Specifications

General

Brand	Acer
Model	AL1714
Category	Monitor
Language	English
