Acer AL1932 User Manual

10
General specifications
Item Specification
LCD Panel
Display 19-inch Flat panel active-matrix TFT LCD
Max resolution SXGA 1280×1024 pixels
Pixel Pitch 0.294 mm
Color 16.2M
Brightness 400 cd/m² (Typical)
Contrast Ratio 500:1 (Typical)
Response Time 12ms (Typical)
View Angle of Horizontal 70° / 70°
View Angle of Vertical 75° / 65°
External Controls
Power Button ON/ OFF
Control Buttons
MENU / / / AUTO
OSD Function
Contrast / Brightness /Color Temp. /Focus / Clock / H-Position /
V-Position
Audio Volume /Mute
Options Auto config. / Information / Reset
Settings Language / OSD H-Position / OSD V-Position / OSD time-out
Video Interface
Video Analog 0.7V
Sync TTL (+/ -)
Audio 2W x 2
Plug & Play DDC2B
Power
Power Source 100~240V AC, 50/60 Hz
Power consumption during
normal operation
50W, approx.
Power consumption during
active off operation
< 2W
Dimension and Weight
Dimension (W×H×D) 455.8X458.5X190.6 mm (with stand)
Weight (Net/ Gross) 7.1 / 10.2 kg

Acer AL1932 Specifications

General

Pixel pitch	0.294 mm
Response time	12 ms
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 80 kHz
Viewable size, vertical	301 mm
Contrast ratio (typical)	500:1
Viewable size, horizontal	376 mm
Viewing angle, horizontal	140 °
Display brightness (typical)	400 cd/m²
Security features	Kensington Lock supported
Speakers and microphone	2x1.1W
Certification	TCO'99
Market positioning	-
I/O ports	-D-Sub mini 15 -DVI-D
Plug and Play	Yes
Panel mounting interface	100 x 100 mm
Power consumption (typical)	50 W

Weight and Dimensions

Depth (without stand)	190.6 mm
Width (without stand)	455.8 mm
Height (without stand)	458.5 mm
Weight (without stand)	7100 g
