5
CONTROLS AND CONNECTORS
CABLE CONNECTIONS
Turn off your computer before performing the procedure below.
1 Plug the power cable of your monitor into a nearby outlet. Plug the other
end of the power cord into the PC port.
2. Connect one end of the 15-pin VGA cable to the back of the monitor and
connect the other end to the computer’s D-Sub port.
3.
(Only dual-input model)Connect one end of the 24-pin DVI cable to the
back of the monitor and connect the other end to the computer’s DVI
port.
4. Turn on your monitor and computer.
Figure 1 Connecting Cables
1. Power Cable
2. Signal Cable
3. DVI Cable(Only dual-input model)
