APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
LCD Panel Size 43.2cm(17.0")
Pixel pitch 0.264mm( H ) × 0.264mm( V )
Brightness 250cd/m
2
(Typical)
Contrast 500:1(Typical)
Viewable angle
75°/ 75° (H) 55°/ 70° (V)
Tr 5 ms (Typical)
Tf 15 ms(Typical)
Video R,G,B Analog Interface
Input H-Frequency 30kHz – 80kHz
V-Frequency 55-75Hz
Display Colors 16.7M Colors
Dot Clock 135MHz
Max. Resolution 1280 × 1024 @75Hz
Plug & Play VESA DDC1/2B
TM
EPA ENERGY STAR
®
ON Mode ≤45W
OFF Mode ≤3W
Input Connector 15-pin D-Sub
Input Video Signal Analog:0.7Vp-p(standard),
75 OHM, Positive
Maximum Screen Size Horizontal : 337.92mm
Vertical : 270.34mm
Power Source 100~264VAC,47~63Hz
Environmental
Considerations
Operating Temp: 5° to 50°C
Storage Temp.: -20° to 65°C
Operating Humidity :
10% to 85%
Dimension 434×407×173(H×W×D)mm
Weight (N. W.) 5.8kg Unit (net)
