Acer Aspire 7730 Series User Manual

13
English
Communication Acer Video Conference, featuring:
• Integrated Acer Crystal Eye webcam*
• Optional Acer Xpress VoIP phone
• WLAN: Intel
®
Wireless WiFi Link 5100/5300*
• WPAN: Bluetooth
®
2.0+Enhanced Data Rate (EDR)*
• LAN: Gigabit Ethernet; Wake-on-LAN ready
• Modem: 56K ITU V.92
Power
subsystem
• ACPI 3.0
• 71 W 4800 mAh*
• 48.8 W 4400 mAh*
• 3-pin 90 W AC adapter*
• 3-pin 65 W AC adapter*
• Engergy Star 4.0
Special keys
and controls
• 105/106-key keyboard
• Touchpad pointing device
• Empowering Key
• Easy-launch buttons:
WLAN, Internet, email, Bluetooth, Acer Arcade
™
• Media keys (printed on keyboard):
play/pause, stop, previous, next
• Volume wheel
• Acer Media Center remote control*
I/O interface
• Acer EasyPort IV connector*
• ExpressCard
™
/54 slot
• 5-in-1 card reader (SD/MMC/MS/MS PRO/xD)
• 4 USB 2.0 ports
• HDMI
™
port with HDCP support*
• Consumer infrared (CIR) port
• External display (VGA) port
• RF-in jack*
• Headphones/speaker/line-out jack with S/PDIF
support*
• Microphone-in jack
• Line-in jack
• Ethernet (RJ-45) port
• Modem (RJ-11) port
• DC-in jack for AC adapter
Environment
• Temperature:
• Operating: 5 °C to 35 °C
• Non-operating: -20 °C to 65 °C
• Humidity (non-condensing):
• Operating: 20% to 80%
• Non-operating: 20% to 80%

Acer Aspire 7730 Series Specifications

General

RAM	Up to 4 GB DDR2
Storage	Up to 320 GB HDD
LAN	Gigabit Ethernet
Webcam	Acer Crystal Eye webcam
Card Reader	5-in-1 card reader
Ports	4 x USB 2.0, HDMI, VGA, Ethernet, Headphone, Microphone
Screen Resolution	1440 x 900
Battery Life	Up to 2.5 hours
Processor	Intel Core 2 Duo
Graphics	NVIDIA GeForce 9600M GT
Optical Drive	DVD-Super Multi double-layer drive
Operating System	Windows Vista
Battery	6-cell Li-ion
Chipset	Mobile Intel PM45 Express
Wireless	802.11a/b/g/n
Screen Size	17 inches
Weight	3.6 kg
