16
English
Base view
# Item Description
1 Battery release latch Releases the battery for removal.
2 Cooling fan Helps keep the computer cool.
Note: Do not cover or obstruct the opening of
the fan.
3 Mini PCI card bay Houses the computer's Mini PCI card.
4 Ventilation slots Enable the computer to stay cool, even after
prolonged use.
5 Memory compartment Houses the computer's main memory.
6 Hard disk bay Houses the computer's hard disk (secured with
screws).
7 Battery lock Locks the battery in position.
8 Battery bay Houses the computer's battery pack.
