12
English
Base view
# Icon Item Description
1 Hard disk bay Houses the computer’s hard disk (secured
with screws)
2 Acer DASP (Disk Anti-
Shock Protection)
Protects the hard disk drive from shocks
and bumps.
3 Ventilation slots and
cooling fan
Enable the computer to stay cool, even
after prolonged use.
Note: Do not cover or obstruct the
opening of the fan.
4 Memory compartment Houses the computer's main memory.
5 Battery lock Locks the battery in position.
6 Battery release latch Releases the battery to remove the
battery pack.
7 Battery bay Houses the computer's battery pack.
