Left view
5 Power indicator Lights when the computer is on.
6 Battery indicator Lights when the battery is being charged.
7 Headphones/
speaker/line-out jack
with S/PDIF support
Connects to audio line-out devices
(e.g., speakers, headphones).
8 Microphone/
line-in jack
Accepts inputs from external sources.
9Bluetooth
communication
button/indicator
Press to enable/disable the Bluetooth
function. Indicates the status of
Bluetooth communication.
10 Wireless
communication
button/indicator
Press to enable/disable the wireless
function. Indicates the status of wireless
LAN communication.
11 Latch Locks and releases the lid.
# Icon Item Description
1 External display port Connects to a display device
(e.g., external monitor, LCD projector).
2 Ventilation slots Enable the computer to stay cool.
3 Ethernet (RJ-45) port Connects to an Ethernet 10/100/1000-
based network.
4 Modem (RJ-11) port Connects to a phone line.
# Icon Item Description
