63
\
Note 1: Design and specifications are subject to change without
notice.
Note 2: * Functions vary depending on model definition.
S1386WHN/S1386WH/T421DT/T421D/XS-W31HG/XS-W31H/F1386WHN/
F1386WH/SE410L/SE410/DS-310T/DS-310/DWX1711/DWX1734
Resolution 1280x800 WXGA resolution
• Maximum: UXGA (1600 x 1200), WSXGA+
(1680x1050), 1080p(1920x1080), WUXGA-RB (1920
x 1200)
Aspect ratio Auto, 4:3, 16:9, L.Box
Optical zoom ratio 1.0X
Throw ratio 0.521 (100"@1.12m)
Projection lens F = 2.8, f = 7.51mm, Manual Focus
Projection screen size (diagonal) 36" ~ 300" (91cm ~ 762cm)
Projection distance 0.4m ~ 3.4m (1.3' ~ 11.0')
Lamp type 220 W user-replaceable lamp
Audio Internal speaker with 16W x 1 output
Weight 3.1 Kg (6.83 lbs)
Dimensions (W x D x H)
(with feet)
313mm x 255.3mm x 113.7mm (12.3" x 10.0" x 4.5")
Power consumption Normal mode: 270W ± 10% @ 110VAC
ECO mode: 210W ± 10% @ 110VAC
Standby mode < 0.5W
I/O connectors S1386WH/T421D/XS-W31H/
F1386WH/SE410/DS-310/
DWX1734
S1386WHN/T421DT/XS-W31HG/
F1386WHN/SE410L/DS-310T/
DWX1711
Power socket V V
VGA IN V X
HDMI V X
Composite video V V
RS232 V V
3.5 mm audio jack input V V
3.5 mm audio jack output V V
5V DC output V X
HDMI 1 X V
HDMI 2/MHL X V
VGA IN 1 X V
VGA IN 2 X V
RJ45 LAN input X V
VGA output V V
USB A1 (Wireless dongle) X V
USB A2 (DC 5V output) X V
