Acer P205H User Manual

Acer Acer –LCD-P205H
48
03 Exploded Diagram
3.1 P205H_SCREW_LIST
Item Part No. Description Qty
Fixed
T(kg*cm)
Remark
1
509146306200R
SCREW,P,CROSS,W/WAS,M3*6,Zn-Cc
5 4.5~5.0
I/F Board to Chassis*1
Power Board to Chassis*4
2
509000000700R BOLT,#4-40x11.8,Ni ROHS 4
4.0
±
0.5
D-SUB CON*2
DVI *2
3
509412610500R
SCREW,B,CROSS,T.T-4*10,BLK ,ROHS
2 6.5±0.5 Hinge to Stand
4
509216608110R
SCREW,F,CROSS,M4*8,Zn,ROHS(NYLOK
,35F)
4
10
±
0.5
Hinge to backcover
5
509212608120R
SCREW,F,CROSS,T4*8,Zn,ROHS(5.8~6.2) 9
6.5
±
0.5
Base Plate to Base
6
509112308500R SCREW,P,CROSS,T.T-3*8,Zn ROHS 1 3.5±0.5 Power Board to backcover
3.2. LCD Exploded drawing (All)

Acer P205H Specifications

General

Pixel pitch	0.276 x 0.276 mm
Aspect ratio	16:9
Display diagonal	20 \
Display resolution	1600 x 900 pixels
Contrast ratio (dynamic)	20000:1
Contrast ratio (typical)	250:1
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Power management	ENERGY STAR
Display viewable area (HxV)	443 x 249 mm
Mean time between failures (MTBF)	50000 h
HDCP	Yes
Certification	CE, TÜV GS, MPRII, ISO 13406-2
Product color	Black
Market positioning	-
LED indicators	Stand-by
Tilt angle range	-5 - 15 °
Panel mounting interface	100 x 100 mm
Power consumption (off)	0.75 W
Power consumption (standby)	0.97 W
Power consumption (typical)	28 W

Weight and Dimensions

Depth (without stand)	190.5 mm
Width (without stand)	478 mm
Height (without stand)	367.5 mm
Weight (without stand)	4200 g
