Acer S240HL User Manual

EN-8
INSTALLATION
To install the monitor to your host system, please follow the steps as given
below:
Steps
1. 1-1 Connect Video Cable
a. Make sure both the monitor and computer are powered-OFF.
b. Connect the VGA video cable to the computer.
1-2 Connect Digital Cable (Only Dual-input model)
a. Make sure both the monitor and computer are powered-OFF.
b. Connect one end of the 24-pin DVI cable to the back of the monitor
and connect the other end to the computer’s port.
1-3 Connect HDMI Cable (Only HDMI-input model)
a. Make sure both the monitor and computer are powered-OFF.
b. Connect the HDMI cable to the computer.
2. Connect the adapter
a. Connect the AC cord to the adapter.
b. Connect one end of the adapter to the monitor and the other end to
a properly grounded, AC outlet.
3. Power-ON Monitor and Computer
Power-ON the monitor first, then power-ON the computer.
This sequence is very important.
4. If the monitor still does not function properly, please refer to the
troubleshooting section to diagnose the problem.
D
HDMI
DC IN
2
HDMI
DVI
D-Sub
DC
D-SubDVI

Acer S240HL Specifications

General

3D	No
Panel type	TN+Film
Screen shape	Flat
Display diagonal	24 \
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	100000000:1
Contrast ratio (typical)	-
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Tilt angle range	-5 - 15 °
Cable lock slot type	Kensington
AC input voltage	110 - 220 V
Annual energy consumption	36 kWh
Power consumption (standby)	- W
Power consumption (typical)	26.1 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight (with stand)	3600 g
Depth (without stand)	45 mm
Width (without stand)	565 mm
Height (without stand)	339 mm
Weight (without stand)	3100 g
