General Specification
Item
Display
15-inch Flat panel active-matrix TFT LCD
Max resolution 1024 x 768 @75Hz
Pixel Pitch 0.297 mm X 0.297 mm
Color 16.2M
Brightness 250nits ( Typical)
Contrast Ratio 450:1 (Typical)
Response Time 16ms (Typical)
View Angle of Horizontal 120°
View Angle of Vertical 100°
External Controls Power Button ON/ OFF
Control Buttons AUTO, MENU, <, >
Video Analog 0.7V
Sync TTL (+/ -)
Plug & Play DDC2B
8
Power Source 100-240V AC, 50/60 Hz, 1.5A
Power consumption during
normal operation
< 25W
Power consumption during
active off operation
< 1W
Dimension (W_H_D) 341x356.4x167.6mm (base included)
Weight (Net/ Gross) 2.6Kg/ 4.1Kg
Specification
Recall
Recall to factory default settings
Video In
VGA
