9
LCD Monitor General Specification
LCD Panel
Driving system TFT Color LCD
Active Display Area 464.94(H) × 290.59mm(V)
Pixel pitch 0.278 (per one triad) x 0.278
Contrast Ratio 1000 : 1
Response time 5ms
Input
Separate Sync. H/V TTL
H-Frequency 30kHz – 83kHz
V-Frequency 56-76Hz
Viewing angle (H)160 (V) 160(Type)
Max. Dot Clock 165MHz
Display mode 1680 × 1050 @60Hz
EPA ENERGY STAR
®
ON Mode < 65W
OFF Mode < 1W
Contrast control
Set to factory preset value, which allows that the brightest two of 32 linear
distributed gray-scales (0～ 700mv) can be distinguished.
Power Source 90~264VAC,47~63Hz
Environmental
Considerations
Operating Temp: 0° to 40°C
Storage Temp: -30° to 60°C
Operating Humidity: 0% to 90%
Storage Humidity: 0% to 90%
Main Dimension(monitor) 518(W)×400 (H)×177(D) mm
Weight:
4.9Kg(monitor)
6.6 Kg(pack monitor)
Peak surge current < 100 A peak at 230 VAC and cold starting&25 & DC Output at Full℃ -load
