11
General specifications
Item Specification
LCD panel
Display 22-inch flat panel active-matrix TFT LCD
Max resolution WXGA+ 1680×1050 pixels
Pixel pitch 0.282 mm
Color 16.7 M
Brightness 300 cd/m² (Typical)
Contrast ratio 1000:1 (Typical)
Response time 5ms (Typical)
View angle of horizontal 170°
View angle of vertical 160°
External controls
Power Button ON/OFF
Control Buttons Auto, menu, minus, plus
OSD Function
Contrast/Brightness Contrast/Brightness
Focus/Clock Focus/Clock
Position Position
Color Color
Language Language
OSD setting OSD Setting
Auto config / Input signal Auto config / Input signal
Information Information
Reset Reset
Exit Exit
Video Interface
Video Analog 0.7 V / Digital HDCP TMDS (Optional)
Sync TTL (+ / -)
Audio 1.5 W x 2(Optional)
Plug & Play DDC2B
Power
Power source
AC 100V~240V 、50 / 60 Hz
Power consumption [Energy Star]
On.
Stand by
OFF
Power consumption
Max.
Stand by
OFF
31.00W
0.80W
0.70W
44.00W
0.80W
0.70W
Dimension and weight
Dimensions (W×H×D) 513.8x417.7x203.8mm (with stand)
Weight (Net/Gross) 5.2kg / 7.4 kg
Lamp disposal
Lamp(s) inside this product contain mercury and must be recycled or disposed of according to local, state
or federal laws. For more information, contact the Electronic Industries Alliance at www.eiae.org
. For
lamp-specific disposal information, check www.lamprecycle.org
.
