18
6-3. Storage and Shipment
CAUTION
Should it be necessary to ship the amplifier, use the original packing as described
below.
Switch off the amplifier, pull the line (mains) plug out of the outlet, disconnect all cables from the rear
panel of the amplifier (remove the ground connection the last), and then pack the amplifier in its original
carton.
a) Acceptable storage environment: The amplifier may be kept packed in a dry, ventilated and unheated
location (with no chemically active substances such as acids or alkalis) within the following environment
ranges:
- Temperature range: -40 to +70 degrees Celsius
- Humidity: up to 75% @ +35 degrees Celsius.
b) Shipping Size and Weight: WxDxH: 535x445x270mm, 21kg (21x17.5x10.6 inches, 46.3Lbs).
c) All types of transportation may be used, including storage in an aircraft baggage compartment at up
to 12000 meters above sea level.
