7 - 10
IS722AN-0 Rev. 160608-0
General Warnings
Technical Characteristics
Power supply voltage 1 0÷16 VDC
GAS output (BLUE wire) rated current 5 A max.
FUEL output (YELLOW wire) rated current 5 A max.
Fuse compliant with DIN 72581 5 A max.
Switch box overall dimensions 24 mm height
77 mm depth
35 mm width
The product is compliant with the following regulations: R 67/01 regulations
R 110/00 regulations
directive 2006/28/EC
Package Contents
The package contains:
1 switch
1switchxingbracket
1 bag of accessories, with wiring harness, fuse, fuse holder and small parts
1 assembly instruction manual
This manual can be modied at any time in order to be updated with all technological,
quality and information changes or improvements
In order to avoid switch malfunctions:
- Lay the switch wires as far as possible from the high voltage cables.
- Make good electrical connections without using cable clamps. Remember that
the best electrical connection is duly insulated soldering.
- Do not replace the 5A fuse with fuses of higher amperage or non-compliant
with the DIN 72581 standards. This can cause irreparable damage.
- Do not open the switch box for any reason whatsoever, especially with the engine
running or with the panel on.
The manufacturer declines all responsibility for damages to things and injuries
to people caused by unauthorised personnel tampering with the device and by
non-observance of the warnings.
