AEG L6FBI947P User Manual

Level of protection against ingress of solid particles and
moisture ensured by the protective cover, except where
the low voltage equipment has no protection against mois‐
ture
IPX4
Water supply pressure Minimum
Maximum
0.5 bar (0.05 MPa)
8 bar (0.8 MPa)
Water supply
1)
Cold water
Maximum Load Cotton 9 kg
Spin Speed Maximum spin speed 1351 rpm
1)
Connect the water inlet hose to a water tap with a 3/4'' thread.
5. INSTALLATION
WARNING!
Refer to Safety chapters.
5.1 Unpacking
1. Open the door. Remove all the items
from the drum.
Accessories delivered
with the appliance may
vary depending on the
model.
2. Put the packaging element on the
floor behind the appliance and
carefully put it down onto its rear
side. Remove the polystyrene
protection from the bottom.
1
2
CAUTION!
Do not lay washing machine
on its front.
3. Put the appliance back into an
upright position. Remove the power
supply cable and the drain hose from
the hose holders.
WARNING!
It is possible to see
water flowing from the
drain hose. This is
because the washing
machine has been
tested at the factory.
www.aeg.com8

AEG L6FBI947P Specifications

General

Door hinge	Right
Cord length	1.8 m
Drum volume	68.6 L
Control type	Rotary, Touch
Door opening	Side opening
Loading type	Front-load
Product color	White
Built-in display	Yes
Door opening angle	160 °
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	9 kg
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	76 dB
Noise level (wash)	- dB
Foam control system	-
Number of washing programs	10
Connected load	2200 W
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.5 W
Water consumption per cycle	50 L
Energy efficiency index (EU 2017/1369)	51.8

Weight and Dimensions

Depth	636 mm
Width	597 mm
Height	847 mm
Depth with door open	1101 mm
Depth with door closed	660 mm
