TECHNICAL DATA
FCLI 2-pipe versions FCLI 32 42 62 82 122
Heating
Heating output 50°C
Speed 4 W - 4950 6250 7100 13000
Speed 3 W 2380 3940 4780 5700 10500
Speed 2 W 1760 3030 3830 4850 8800
Speed 1 W 1330 2250 3050 3500 6300
Pressure drop (VL)
Speed 4 kPa - 23 32 23 34
Speed 3 kPa 9 16 21 15 24
Speed 2 kPa 6 10 15 11 17
Speed 1 kPa 4 6 10 6 9
Cooling
Cooling capacity
Speed 4 W - 3950 4980 6000 11000
Speed 3 W 1900 3250 3940 4790 8950
Speed 2 W 1470 2540 3210 4050 7500
Speed 1 W 1160 1960 2660 2800 5360
Sensible cooling capacity
Speed 4 W - 3160 3810 4200 8470
Speed 3 W 1520 2360 2810 3300 6870
Speed 2 W 1250 1820 2270 2770 5730
Speed 1 W 990 1380 1860 1900 4040
Water fl ow rate
Speed 4 l/h - 679 857 1032 1892
Speed 3 l/h 327 559 678 824 1539
Speed 2 l/h 253 437 552 697 1290
Speed 1 l/h 200 337 458 482 922
Pressure drop (VL)
Speed 4 kPa - 25 36 25 38
Speed 3 kPa 10 18 24 17 26
Speed 2 kPa 7 11 16 12 19
Speed 1 kPa 4 7 12 6 10
Common data
Fans no.11111
Air fl ow rate
Speed 4 m3/h - 700 880 1100 1750
Speed 3 m3/h 600 530 660 830 1350
Speed 2 m3/h 410 360 500 680 1100
Speed 1 m3/h 300 260 380 460 750
Sound power
Speed 4 dB(A) - 53 61 50 60
Speed 3 dB(A) 46 46 54 45 54
Speed 2 dB(A) 38 38 47 43 50
Speed 1 dB(A) 35 35 41 39 44
 Sound pressure
Speed 4 dB(A - 44 52 41 51
Speed 3 dB(A 37 37 45 36 45
Speed 2 dB(A 29 29 38 34 41
Speed 1 dB(A) 26 26 32 30 35
Input power
Speed 4 W - 75 83 150 175
Speed 3 W 45 47 53 105 125
Speed 2 W 31 32 37 80 105
Speed 1 W 21 22 26 45 55
Input current (max speed) A 0.22 0.33 0.37 0,70 0.75
Starting current A 0.66 0.99 1.11 2.10 2.25
Power supply V / Hz 230V~50Hz
Maximum protection level IP 20 20 20 20 20
Heat exchanger water content L 1.2 1.5 2.1 3 4.5
Water connections Ø gas 3/4” 3/4” 3/4” 3/4” 3/4”
Kvs (3-way valve, standard version) 2.5 2.5 2.5 4 4
Kvs (2-way valve, V2 version) 2.5 2.5 2.5 2.5 2.5
 Level of sound pressure (A-weighted) measured in the room with
volume V = 100 m
3
, reverberation time t = 0.5 s; direction factor
Q = 2; distance r = 2.5m
Cooling:
• External air temperature 27°C D.B. ; 19°C W.B.
•Water inlet temperature 7°C ; t water 5°K
Heating 50°C:
• External air temperature 20°C
•Water inlet temperature: 50°C; t water 10°K
Heating 70°C:
• External air temperature 20°C
•Water inlet temperature: 50°C; t water 10°K
The leakage current to earth of several
devices placed under the same circuit
breaker is summed, so attention should be
paid to the calibration of the circuit breaker
and possibly consider the division of the
installation into several circuits each of
which protected by its own circuit breaker.
= Performance certified EUROVENT 6/3 - Sound tests certified EUROVENT 8/2 (ISO 3741/2001)
Performance values refer to the following conditions:
