[1] Specifications are for 1 hr warm-up and 6
1
/2 digits, Slow ac filter
[2] Relative to calibration standards
[3] 20% over range on all ranges except 300 Vdc and ac ranges and 1 Adc and ac
current ranges
[4] For sinewave input > 5% of range. For inputs from 1% to 5% of range and
< 50 kHz, add 0.1% of range additional error
[5] Typically 30% of reading error at 1 MHz, limited to 1 x 10
8
V Hz
[6] Specifications are for 4- wire ohms function or 2-wire ohms using Scaling
to remove the offset. Without scaling, add 4 Ω additional error in 2-wire
Ohms function
[7] Input > 100 mV. For 10 mV to 100 mV inputs multiply % of reading error x 10
[8] Specified only for inputs >10 mA
[9] For total measurement accuracy, add temperature probe error
[10] Thermocouple specifications not guaranteed when 34907A module is present
Accuracy Specifications ±(% of reading + % of range)
[1]
Includes measurement error, switching error, and transducer conversion error
Temperature
Range
[3]
Frequency, etc. 24 Hour
[2]
90 Day 1 Year Coefficient
23°C±1°C 23°C±5°C 23°C±5°C 0°C–18°C, 28°C–55°C
DC Voltage
100.0000 mV 0.0030 + 0.0035 0.0040 + 0.0040 0.0050 + 0.0040 0.0005 + 0.0005
1.000000 V 0.0020 + 0.0006 0.0030 + 0.0007 0.0040 + 0.0007 0.0005 + 0.0001
10.00000 V 0.0015 + 0.0004 0.0020 + 0.0005 0.0035 + 0.0005 0.0005 + 0.0001
100.0000 V 0.0020 + 0.0006 0.0035 + 0.0006 0.0045 + 0.0006 0.0005 + 0.0001
300.000 V 0.0020 + 0.0020 0.0035 + 0.0030 0.0045 + 0.0030 0.0005 + 0.0003
True RMS AC Voltage
[4]
100.0000 mV 3 Hz–5 Hz 1.00 + 0.03 1.00 + 0.04 1.00 + 0.04 0.100 + 0.004
to 100.0000V 5 Hz–10 Hz 0.35 + 0.03 0.35 + 0.04 0.35 + 0.04 0.035 + 0.004
10 Hz–20 kHz 0.04 + 0.03 0.05 + 0.04 0.06 + 0.04 0.005 + 0.004
20 kHz–50 kHz 0.10 + 0.05 0.11 + 0.05 0.12 + 0.05 0.011 + 0.005
50 kHz–100 kHz 0.55 + 0.08 0.60 + 0.08 0.60 + 0.08 0.060 + 0.008
100 kHz–300 kHz
[5]
4.00 + 0.50 4.00 + 0.50 4.00 + 0.50 0.20 + 0.02
300.0000V 3 Hz–5 Hz 1.00 + 0.05 1.00 + 0.08 1.00 + 0.08 0.100 + 0.008
5 Hz–10 Hz 0.35 + 0.05 0.35 + 0.08 0.35 + 0.08 0.035 + 0.008
10 Hz–20 kHz 0.04 + 0.05 0.05 + 0.08 0.06 + 0.08 0.005 + 0.008
20 kHz–50 kHz 0.10 + 0.10 0.11 + 0.12 0.12 + 0.12 0.011 + 0.012
50 kHz–100 kHz 0.55 + 0.20 0.60 + 0.20 0.60 + 0.20 0.060 + 0.020
100 kHz–300 kHz
[5]
4.00 + 1.25 4.00 + 1.25 4.00 + 1.25 0.20 + 0.05
Resistance
[6]
100.0000Ω 1 mA current source 0.0030 + 0.0035 0.008 + 0.004 0.010 + 0.004 0.0006 + 0.0005
1.000000 kΩ 1 mA 0.0020 + 0.0006 0.008 + 0.001 0.010 + 0.001 0.0006 + 0.0001
10.00000 kΩ 100 µA 0.0020 + 0.0005 0.008 + 0.001 0.010 + 0.001 0.0006 + 0.0001
100.0000 kΩ 10 µA 0.0020 + 0.0005 0.008 + 0.001 0.010 + 0.001 0.0006 + 0.0001
1.000000 MΩ 5.0 µA 0.002 + 0.001 0.008 + 0.001 0.010 + 0.001 0.0010 + 0.0002
10.00000 MΩ 500 nA 0.015 + 0.001 0.020 + 0.001 0.040 + 0.001 0.0030 + 0.0004
100.0000 MΩ 500 nA/10 MΩ 0.300 + 0.010 0.800 + 0.010 0.800 + 0.010 0.1500 + 0.0002
Frequency and Period
[7]
100 mV 3 Hz–5 Hz 0.10 0.10 0.10 0.005
to 300 V 5 Hz–10 Hz 0.05 0.05 0.05 0.005
10 Hz–40 Hz 0.03 0.03 0.03 0.001
40 Hz–300 kHz 0.006 0.01 0.01 0.001
DC Current (34901A only)
10.00000 mA <0.1 V burden 0.005 + 0.010 0.030 + 0.020 0.050 + 0.020 0.002+ 0.0020
100.0000 mA <0.6 V 0.010 + 0.004 0.030 + 0.005 0.050 + 0.005 0.002 + 0.0005
1.000000 A <2 V 0.050 + 0.006 0.080 + 0.010 0.100 + 0.010 0.005 + 0.0010
True RMS AC Current (34901A only)
10.00000 mA 3 Hz–5 Hz 1.00 + 0.04 1.00 + 0.04 1.00 + 0.04 0.100 + 0.006
and
[4]
1.000000 A 5 Hz–10 Hz 0.30 + 0.04 0.30 + 0.04 0.30 + 0.04 0.035 + 0.006
10 Hz–5 kHz 0.10 + 0.04 0.10 + 0.04 0.10 + 0.04 0.015 + 0.006
100.0000 mA
[8]
3 Hz–5 Hz 1.00 + 0.5 1.00 + 0.5 1.00 + 0.5 0.100 + 0.06
5 Hz–10 Hz 0.30 + 0.5 0.30 + 0.5 0.30 + 0.5 0.035 + 0.06
10 Hz–5 kHz 0.10 + 0.5 0.10 + 0.5 0.10 + 0.5 0.015 + 0.06
Temperature Type 1-Year Accuracy
[9]
Extended Range 1-Year Accuracy
[9]
Thermocouple
[10]
B 1100°C to 1820°C 1.2°C 400°C to 1100°C 1.8°C
E -150°C to 1000°C 1.0°C -200°C to -150°C 1.5°C
J -150°C to 1200°C 1.0°C -210°C to -150°C 1.2°C
K -100°C to 1200°C 1.0°C -200°C to -100°C 1.5°C
0.03 °C
N -100°C to 1300°C 1.0°C -200°C to -100°C 1.5°C
R 300°C to 1760°C 1.2°C -50°C to 300°C 1.8°C
S 400°C to 1760°C 1.2°C -50°C to 400°C 1.8°C
T -100°C to 400°C 1.0°C -200°C to -100°C 1.5°C
RTD R
0
from 49 Ω to 2.1 kΩ -200°C to 600°C 0.06°C 0.003 °C
Thermistor 2.2 k, 5k, 10k -80°C to 150°C 0.08°C 0.002 °C
