Agilent Technologies 490 Micro GC User Manual

Checkout Information 2
Natural Gas Analyzers 19
Analysis of the Universal Gas Calibration standard results in a
chromatogram similar to Figure 17.
Analysis of a sample containing hydrogen sulfide results in a
chromatogram similar to Figure 18.
Figure 17 Universal Gas Calibration standard analyzed with the PoraPLOT U channel on Analyzer B
Figure 18 Sample containing hydrogen sulfide analyzed with the PoraPLOT U channel on Analyzer B
Seconds
20 25 30 35 40 45 50 55 60 65
mV
0
10
20
Nitrogen
Carbon Dioxide
Ethylene
Ethane
Acetylene
Propane
Methane
Seconds
20
25 30 35 40 45 50 55 60 65
mV
0
25
50
75
Carbon Dioxide
Ethane
Hydrogen Sulfide Propane
Nitrogen
Methane
