EXPLODED VIEWS AND SPARE PARTS LISTS
SM FLODCI 2-A.4 GB
14.2 Intdoor Unit: FLO 18, FLO 21 DCI
Item No. Part No. Description Qty
1A 452917400 Grill A/FLO18 1
1B 452952800 Grill B/FLO18 1
1C 452952900 Grill C/FLO18 1
2A 453080400 Display Board Assy.906-257-00 1
3 452919800 Filter 2
4 4518113 Fiber Filter Assy. (Optional) 1
5 453054000 Frame assy./FLO18 1
6A 4526946 Display Lens Assy(LCD) 1
6B 4527144 Display Cover Assy 1
7 452919600 Screw cover 3
8 433133 IONIZER DISPLAY 906-191-07 (Optional) 1
8A 452919700 Cover/Ionizer (Optional) 1
9 453134600 Evaporator Assy. 1
10 4518664 Drain hose 1
11 452917300 Air outlet 1
12 453050200 STEP MOTOR A 1
13 452918700 Support/horizontal louver 2
14 452917500 Horizontal flap A 1
14 452917600 Horizontal flap B 1
16 452918500 Linkage A 1
452918600 Linkage B 1
17 452930700 Vertical flap A 12
452918200 Vertical flap B 2
18 452918300 Tie/vertical flap A 1
452918400 Vertical flap stator B 2
452953000 Vertical flap stator C 1
19 4518662 Bearing assy fan 1
20 453024900 Impeller fan 1
21 453053800 Base assy./FLO18 1
22 4518657 TUBE LOCK 1
23 452920100 Mount bracket/FLO-18 20 1
24 452919400 Joint/Unit housing 1
25 453024500 PG Motor 1
26 4518651 Cover Side Motor 1
27 452918800 Cover/motor 1
28 453042500 Remote controller/RC4-I-1 EHK P/N 974-710-00 1
29 453050300 STEP MOTOR B 1
30 453057900 Gear BOX ASSY 1
31 453109300 Wire UL100726AWG/Ionizer 1
32 433134 IONIZER POWER 906-191-01 (Optional) 1
33 4517022 Plug 1
34 4524967 IONIZER WIRE A (Optional) 1
35 453030600 Indoor DC Inverter Controller(ENGLISH)916-513-00 1
36 4524963 Electrostatic Filter (Optional) 1
37 452919500 Cover/terminal 1
