Translation of original user instructions GB 2
Store fuel only in containers specifically designed
fort he storage of such materials.
Add fuel outdoors only. Do not smoke when
fuelling!
Never open the cap of the fuel tank, or add fuel,
while the engine is running or the unit is hot.
Always use a funnel or a filling pipe for adding
fuel to avoid the spilling of the fuel onto the
engine, the cover ort he ground.
If the fuel overflows the engine must not be
started. The unit is necessary to be cleaned. In
no case the unit is allowed to be started until the
petrol vapours disperse.
For security reasons always replace the fuel tank
and its cap when being damaged.
Risk of burning injuries!
The exhaust pipe and parts close to it may
be hot up to 80°.
Replace the damaged parts of the exhaust pipe.
Do not change the setting of the engine regula-
tor.
Never run the internal-combustion engine inside
a closed room – intoxication risk!
Spare parts and accessory
Only use the original spare parts and original
accessory.
The producer reserves all rights to change the
construction or configuration.
Safety symbols on the unit
Read the operating instructions
before operating the unit.
Rotating unit. Keep hands and
feet from the unit.
Use
Designated use
This unit is determined for processing in advance
hoed soil.
The unit is not suitable to process the solid soil,
e.g. firmly down-trodden lawn.
Other use of this device with original accessories
is allowed only for the determined purposes.
Operating times:
Please observe the operating hours permitted
locally.
Assembly
The assembly of this machine – see the figures
1 - 16.
Parts description
1 Clutch lever
2 Throttle lever
3 Lever for reverse gear
4 Starter rope
5 Transport wheel
6 Chopping knife
7 Protective glass
8 Guard
9 Brake spur
Putting into Operation
Put the machine into operation only after its
complete assembly.
Tank Oil and Petrol before the First Putting
into Operation! It is necessary to respect
unconditionally instructions in enclosed
operating instructions for petrol engine
delivered by engine producer.
Setting-up of Handle Height
Set-up handle height according to your proper
body size.
Common setting-up of height corresponds to
haunch height.
Loose screws on cover support.
Set-up handle height according to long
holes.
Tighten screws.
With the models with reverse gear
(MH xxxx R) the guide handle can be
swung to the left and right.
Loosen the star knob (Fig. 14), swing the
guide handle to the side and tighten the star
knob manually.
Transport Wheel
Motor cutter can be transported to given place by
means of transport wheel.
To work with the motor-driven weeder, remove
the transport wheel.
