8 MONO INPUT CHANNEL EXPANDER
OPTIONS & ACCESSORIES
There are a range of options and accessories available for the GL3300 range. All are supplied complete
with fixings and installation and operating instructions. Contact your nearest Allen & Heath dealer if you
wish to purchase an option or accessory.
VU meterbridge
The VU meterbridge is designed for use in all lighting conditions and monitors Groups (Aux) 1-8, Left,
Right and Mono/PFL signal levels. It fits onto the rear extrusion beam of the console and is full length.
The meterbridges are available in 3 sizes. Please note, there is no meterbridge option avaiable for the 16
channel frame.
M
SM
GL3300-M24 VU METERBRIDGE Order Code: GL3300-M24
To fit GL3300 24 input channel console
GL3300-M32 VU METERBRIDGE Order Code: GL3300-M32
To fit GL3300 32 input channel console
GL3300-M40 VU METERBRIDGE Order Code: GL3300-M40
To fit GL3300 40 input channel console
Expander
The GL3300 can be expanded up to a maximum of 40 input channels. The expander is an 8 channel wide
bolt on module with full function input channels and soft armrest.It can be fitted to the left or right hand
side of the console depending on the console format. The expanders are available in 4 different formats.
Order Code: GL3300-8M
8 STEREO INPUT CHANNEL EXPANDER
S
Order Code: GL3300-8S
4 MONO & 4 STEREO INPUT CHANNEL EXPANDER
Order Code: GL3300-4MS
MS
4 STEREO & 4 MONO INPUT CHANNEL EXPANDER
Order Code: GL3300-4SM
SYS-LINK Buss Expander Kit
The SYS-LINK expander option allows console to console interconnection by means of just two cables.
By connecting two GL3300 consoles together or to any other A&H console fitted with the SYS-LINK
option, the number of input channels can be increased. One console acts as a channel expander (slave)
to the second (master). Please note, the SYS-LINK option kit requires the installation and wiring of a
circuit board (PCB) assembly and should only be fitted by technically competent service personnel
SYS-LINK BUSS EXPANDER KIT Order Code: GL3300-SL1
(for one console only)
8 Group Output option Kit
The 8 Group Output option allows direct access to all 8 groups in the console. This is in addition to group
outputs 5-8 on XLR connectors on the rear panel. This option uses one of the SYS-LINK connector
mounting holes and may need to be repositioned if the SYS-LINK option is already fitted. Please note,
the 8 Group Output option kit requires the installation and wiring of a circuit board (PCB) assembly and
should only be fitted by technically competent service personnel
8 GROUP OUTPUT OPTION KIT Order Code: GL3300-8GD

ALLEN & HEATH GL3300 Specifications

General

Aux Sends	6
Power Supply	Internal
Type	Analog
Number of Channels	40
Phantom Power	Yes
Direct Outputs	Yes
Metering	LED
Frequency Response	20Hz - 20kHz
Noise (EIN)	-128dB
