Allen & Heath 32 GS_R24 User Guide
MIDI Default data: ch = MIDI channel
MIDI IMPLEMENTATION
MIDI Implementation
There are two implementation modes for GS-R24:
1) The default set of MIDI data messages that is unique to GS-R24 which can be mapped, learned or translated by DAW
application software or MIDI translator software.
2) An emulation of the US 2400 MIDI control surface made by TASCAM.
MIDI
CONTROLLER
MESSAGE
TYPE
DATA 1 DATA 2
FADER CH1 0xB(ch) 0x01 0x(0-7F)
FADER CH2 0xB(ch) 0x02 0x(0-7F)
FADER CH3 0xB(ch) 0x03 0x(0-7F)
FADER CH4 0xB(ch) 0x04 0x(0-7F)
FADER CH5
0xB(ch)
0x05 0x(0-7F)
FADER CH6 0xB(ch) 0x06 0x(0-7F)
FADER CH7
0xB(ch)
0x07 0x(0-7F)
FADER CH8
0xB(ch)
0x08 0x(0-7F)
FADER CH9
0xB(ch)
0x09 0x(0-7F)
FADER CH10
0xB(ch)
0x0A 0x(0-7F)
FADER CH11
0xB(ch)
0x0B 0x(0-7F)
FADER CH12
0xB(ch)
0x0C 0x(0-7F)
FADER CH13
0xB(ch)
0x0D 0x(0-7F)
FADER CH14
0xB(ch)
0x0E 0x(0-7F)
FADER CH15
0xB(ch)
0x0F 0x(0-7F)
FADER CH16
0xB(ch)
0x10 0x(0-7F)
FADER CH17
0xB(ch)
0x11 0x(0-7F)
FADER CH18
0xB(ch)
0x12 0x(0-7F)
FADER CH19
0xB(ch)
0x13 0x(0-7F)
FADER CH20
0xB(ch)
0x14 0x(0-7F)
FADER CH21
0xB(ch)
0x15 0x(0-7F)
FADER CH22
0xB(ch)
0x16 0x(0-7F)
FADER CH23
0xB(ch)
0x17 0x(0-7F)
FADER CH24
0xB(ch)
0x18 0x(0-7F)
FADER Mono M 0xB(ch) 0x21 0x(0-7F)
MIDI
CONTROLLER
MESSAGE
TYPE
DATA 1 DATA 2 SHIFT
DATA 1
ROTARY 1 0xB(ch) 0x40 0x(0-7F) 0x4E
ROTARY 2 0xB(ch) 0x41 0x(0-7F) 0x4F
ROTARY 2 0xB(ch) 0x42 0x(0-7F) 0x50
ROTARY 4 0xB(ch) 0x43 0x(0-7F) 0x51
ROTARY 5
0xB(ch)
0x44 0x(0-7F) 0x52
ROTARY 6 0xB(ch) 0x45 0x(0-7F) 0x53
ROTARY 7
0xB(ch)
0x46 0x(0-7F) 0x54
ROTARY 8
0xB(ch)
0x47 0x(0-7F) 0x55
ROTARY 9
0xB(ch)
0x48 0x(0-7F) 0x56
ROTARY 10
0xB(ch)
0x49 0x(0-7F) 0x57
ROTARY 11
0xB(ch)
0x4A 0x(0-7F) 0x58
ROTARY 12
0xB(ch)
0x4B 0x(0-7F) 0x59
FADER 1
0xB(ch)
0x4C 0x(0-7F) 0x5A
FADER 2 0xB(ch) 0x4D 0x(0-7F) 0x5B
MIDI
CONTROLLER
MESSAGE
TYPE
DATA 1 DATA 2 DATA 3 DATA 4 DATA5 DATA 6
REW MMC 0xF0 0x7F 0x7F 0x06 0x05 0xF7
STOP MMC 0xF0 0x7F 0x7F 0x06 0x01 0xF7
PLAY MMC 0xF0 0x7F 0x7F 0x06 0x02 0xF7
FFW MMC 0xF0 0x7F 0x7F 0x06 0x04 0xF7
REC MMC 0xF0 0x7F 0x7F 0x06 0x06 0xF7
MIDI
CONTROLLER
MESSAGE
TYPE
DATA 1 DATA 2 ON/OFF
REW 0x9(ch) 0x67 0x7F ON
REW 0x8(ch) 0x67 0x00 OFF
STOP 0x9(ch) 0x68 0x7F ON
STOP 0x8(ch) 0x68 0x00 OFF
PLAY 0x9(ch) 0x69 0x7F ON
PLAY 0x8(ch) 0x69 0x00 OFF
FFW
0x9(ch)
0x6A 0x7F ON
FFW
0x8(ch)
0x6A 0x00 OFF
REC
0x9(ch)
0x6B 0x7F ON
REC 0x8(ch) 0x6B 0x00 OFF
