ALLEN&HEATH iDR-32 iDR 48 service manual AP7567 issue 4 Page - 11 - of 17
SERVICE ACCESS
PZ1
1. Remove x3 screws from under front.
2. Remove x3 screws from rear top.
3. Remove x8 screws from sides.
