Allen-Bradley 1734-IE2C User Manual

12 POINT I/O 2 Current and 2 Voltage Input Analog Modules
Publication 1734-IN027C-EN-E - October 2016
Wire the Module
To wire the module, refer to the diagrams and tables.
WARNING: If you connect or disconnect wiring while the field-side power is
on, an electrical arc can occur. This could cause an explosion in hazardous
location installations. Be sure that power is removed or the area is
nonhazardous before proceeding.
Module status
Network status
Status of input 0
Status of input 1
Input 0
Chas gnd
C
Chas gnd
Input 1
41974
C
V
V
Chas gnd = Chassis ground
C = Common
V = Supply
CC
VV
Analog
Voltage
Input
Module
Status
Network
Status
1734
IE2V
NODE:
0
1
Input 0
Chas gnd Chas gnd
Input 1
1734-IE2C 1734-IE2V

Allen-Bradley 1734-IE2C Specifications

General

Brand	Allen-Bradley
Model	1734-IE2C
Category	I/O Systems
Language	English
