Allen-Bradley 1746 Series User Manual

Discrete I/O Modules 19
Publication 1746-IN005A-US-P
Output Modules - dc
Table 13:Specifications for Output Modules 1746-OB8, -OB16, and -OB16E
Specification
Catalog Number 1746-
OB8 OB16
(1)
(1)Removable Terminal Block.
OB16E
(1)(2)
(2)Use the following ID Code when configuring your system with programming software or
the HHT: 1746-OB16E = 2920.
Number of Outputs 81616
Points per Common 81616
Voltage Category 24V dc Signal Output
Operating Voltage (V dc) 10 to 50 (source)
10 to 30
(source)
Backplane Current
Consumption
5V dc 0.135A 0.280A 0.135A
24V dc 0.0A
Signal Delay (max.).
Resistive Load.
on = 0.1 ms
off = 1.0 ms
on = 0.1 ms
off = 1.0 ms
on = 1.0 ms
(3)
off = 1.0 ms
(3)Fast turn-off modules (1746-OB6EI, -OBP8 Series B and later, -OB16E Series B and
later, -OBP16, and
-OVP16) provide fast OFF delay for inductive loads. Comparative OFF delay times for
1746-OB8/-OV8 and fast turn-off modules, when switching Bulletin 100-B110 (24W
sealed) contactor, are: 1746-OB8/-OV8 OFF delay = 152 ms; fast turn-off modules OFF
delay = 47 ms.
Off State Leakage (max.)
(4)
(4)To limit the effects of leakage current through solid state outputs, a loading resistor can
be connected in parallel with your load. For transistor outputs, 24V dc operation, use a
5K
Ω
, 1/2W resistor.
1 mA
Load Current (min.) 1 mA
Continuous Current per
Point
(5)
1.0A at 30°C
0.50A at 60°C
0.50A at 30°C
0.25A at 60°C
1.0A at 30°C
(6)
0.50A at 60°C
Continuous Current per
Module
8.0A at 30°C
4.0A at 60°C
8.0A at 30°C
4.0A at 60°C
8.0A at
0 to 60°C
On State Voltage Drop (max.) 1.2V at 1.0A 1.2V at 0.50A 1.0V at 0.50A
Surge Current per Point
(7)
3.0A for 10 ms 3.0A for 10 ms
2.0A for 10
ms
(8)
