ControlLogix Power Supply
Additional Resources
These documents contain additional information concerning related products from Rockwell Automation.
You can view or download publications at http://www.rockwellautomation.com/literature/
. To order paper copies of technical documentation,
contact your local Allen-Bradley distributor or Rockwell Automation sales representative.
Attribute 1756-PAXT 1756-PBXT 1756-PA30XT 1756-PB30XT
Voltage and current ratings Input: 120/240V AC,
50/60 Hz, 82VA, 64 W
Output: 1.75 A, 24V DC, 8 A,
5.1V DC, 4 A, 3.3V DC, 1.5 A,
1.2V DC, 42 W max, 20 A inrush
max
Input: 18…32V DC, 54 W
Output: 1.75 A, 24V DC, 8 A,
5.1V DC, 4 A, 3.3V DC, 1.5 A,
1.2V DC, 42 W max, 30 A inrush
max
Input: 120/240V AC, 50/60 Hz,
50 W (60VA), 70 °C (158 °F)
Output: 1.25 A, 24V DC; 6 A,
5.1V DC; 2 A, 3.3V DC; 1.5 A,
1.2V DC; 30 W max, 20 A inrush
max
Input: 24V DC, 50W
70 °C (158 °F)
Output: 1.25 A, 24V DC; 6 A,
5.1V DC; 2 A, 3.3V DC; 1.5 A,
1.2V DC; 30 W max, 20 A inrush
max
Isolation voltage 250V (continuous), Reinforced Insulation Type, Power Input to Backplane
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
-25 °C < Ta < +70 °C (-13 °F < Ta < +158 °F)
Temperature, surrounding air, max 70 °C (158 °F)
Enclosure type rating None (open-style)
Torque 0.8 N•m (7 lb•in)
Dimensions (HxWxD), approx 14.0 x 11.2 x 14.5 cm (5.51 x 4.41 x 5.71 in.) 14.0 x 7.8 x 14.5 cm (5.51 x 3.07 x 5.71 in.)
Wire size 2.5 mm² (14 AWG) solid or stranded copper wire rated at 90 °C (194 °F), or greater, 1.2 mm (3/64 in.) insulation max
North American temperature code T4 T4A T4
ATEX temperature code - T4 - T4
IECEx temperature code - T4 - T4
Resource Description
1756 ControlLogix Specifications Technical Data, publication 1756-TD006 Provides technical specifications for ControlLogix chassis.
1756 ControlLogix Power Supplies Specifications Technical Data, publication 1756-TD005 Provides technical specifications for ControlLogix power supplies.
ControlLogix Chassis Installation Instructions, publication 1756-IN621 Provides information on how to install ControlLogix chassis.
ControlLogix System User Manual, publication 1756-UM001 Provides instructions for installation and use of ControlLogix Systems, application design, and other
general information for these systems.
Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1
Provides general guidelines for installing a Rockwell Automation industrial system.
Product Certifications website, http://www.rockwellautomation.com/rockwellautomation/
certification/overview.page
Provides declarations of conformity, certificates, and other certification details.
