30 PanelView Component HMI Terminals
Publication 2711C-IN001H-EN-P - July 2014
Backlight Disposal
Specifications
IMPORTANT
The backlight assembly in the PanelView C600 (2711C-T6M, 2711C-T6C only) and C1000
devices contain mercury. At the end of its life, this equipment should be collected separately
from unsorted municipal waste.
PanelView Component - 2711C-F2M, 2711C-K2M, 2711C-T3M, 2711C-K3M, 2711C-T6M,
2711C-T4T, 2711C-T6C, 2711C-T6T, 2711C-T10C
Attribute Value
C200 C300 C400 C600 C1000
Display type Monochrome
transflective STN
passive matrix
Monochrome
transflective FSTN
passive matrix
Color transmissive
TFT active matrix
LCD
Monochrome
transmissive FSTN
passive matrix or
Color transmissive
CSTN passive matrix
or
Color transmissive
TFT active matrix
LCD
Color
transmissive TFT
active matrix LCD
Display size 2 in. 3 in. 4 in. 5.7 in. 10.4 in.
Display area 49 x 14 mm
(1.93 x 0.55 in.)
67 x 33 mm
(2.64 x 1.30 in.)
95.04 x 53.86 mm
(3.74 X 2.12 in.)
115 x 86 mm
(4.53 x 3.39 in.)
211 x 158 mm
(8.31 x 6.22 in.)
Resolution
(pixels)
122 x 32 128 x 64 480 X 272 320 x 240 640 x 480
Backlight 50,000 hours life, min., backlight not
replaceable
40,000 hours life,
min., backlight not
replaceable
50,000 hours life, min., backlight not
replaceable
Yellow/Green LED
indicator
White LED indicator For 2711C-T6C and 2711C-T10C – CCFL
For 2711C-T6T – 40,000 hours life, min.,
White LED backlight, not replaceable
Operator input Function keys or
combination
function keys and
numeric keypad
Analog touch or
combination
function keys and
numeric keypad
Analog touch and
function keys
Analog touch
Memory card USB port USB port and Secure digital (SD) card
Programming
port
USB device port
Battery life,
min.
5 years at 25 °C (77 °F)
Real-time clock No battery backup Battery backup
Input voltage
range
18…30V DC (24V DC nom)
