Allen-Bradley PanelView Plus 1500 User Manual

Publication 2711P-UM001A-EN-P
Installation 2-7
Cutout Dimensions
This section provides panel cutout dimensions for each terminal. Use
the full size template shipped with your terminal to mark the cutout
dimensions. All dimensions are in mm (inches).
PanelView Plus Terminal Height Width
PanelView Plus 700 Keypad or Keypad & Touch 167 (6.57) 264 (10.39)
PanelView Plus 700 Touch 154 (6.08) 220 (8.67)
PanelView Plus 1000 Keypad or Keypad & Touch 224 (8.8) 375 (14.75)
PanelView Plus 1000 Touch 224 (8.8) 305 (12.00)
PanelView Plus 1250 Keypad or Keypad & Touch 257 (10.11) 390 (15.35)
PanelView Plus 1250 Touch 257 (10.11) 338 (13.29)
PanelView Plus 1500 Keypad or Keypad & Touch 305 (12.00) 419 (16.50)
PanelView Plus 1500 Touch 305 (12.00) 391 (15.40)
