Ethernet Switches
Stratix 6000
9-10
Visit our website: www.ab.com/catalogs
Publication M117-CA001A-EN-P
Fixed Managed Switches
General Quick Selection 9-Ethernet
Switches
Connection
Systems
PannelConnect Safety
Connection
6-Ethernet
Switches
1783-EMS04T 1783-EMS08T
Ports per Module 4 (9) 8 +1 SFP slot
Copper Ports 4 10/100 full/half duplex 8 10/100 full/half duplex
Fiber Ports
⎯
supports 1 G fiber SFP
SFP Slots
⎯
1
CompactFlash Memory No
Power Requirements
12…48V DC
Class 2/SELV
100 mA at 24V DC
12…48V DC
Class 2/SELV
250 mA at 24V DC
Inrush Current, Max. 2.2 A
Power Dissipation 2.6 W @ 60 °C (140 °F) max 5.8 W @ 60 °C (140 °F) max
Fiber Optic Ethernet Data Rate
⎯
1000 Mbps
1
Fiber Optic Connector Type
⎯
LC1
1
Available with optional SFP module.
Feature Benefit
RSLogix 5000 AOP (Add On Profile) Enables easy switch setup and diagnostics with Logix controllers and the Integrated Architecture.
VLAN (Virtual LAN) with trunking Helps ease network management in the production network.
QoS (Quality of Service) Enables prioritization of applications, users, or data flows to help provide a higher level of network predictability.
Bandwidth Threshold Alarming Supports alarms to track network changes and detect malfunctioning devices.
MAC ID Port Security Enables tracking network changes from the controller through new MAC ID notifications.
DHCP per port Supports assigning a specific IP address to each port, enabling device replacement without manually configuring IP
addresses.
IGMP (Internet Group Management
Protocol) Snooping and Querier
Reduces multicast traffic from intensive IP applications, such as I/O control on EtherNet/IP.
Port Mirroring Copies network traffic seen on one switch port to another. Typically used as a diagnostic tool.
Key Software Features
Technical Specifications
