Environmental Specifications and Certifications
Stratix 8000/8300 Switches Stratix 6000 Switches Stratix 2000 Switches
EtherNet/IP Taps with
Embedded Switch
Technology
Operating Temperature
-40…60 °C
(-40…140 °F)
0…60 °C
(32…140 °F)
0…60 °C
(32…140 °F)
Copper tap:
 -25…70 °C
(-13…158 °F)
Fiber tap:
 -25…60 °C
(-13…140 °F)
Enclosure Type Rating IP20 IP20 IP20 None (open-style)
Relative Humidity 5…95% noncondensing 5…95% noncondensing 5…95% noncondensing 5…95% noncondensing
Vibration 2 g at 10…500 Hz 2 g at 10…500 Hz 2 g at 10…500 Hz 5 g at 10…500 Hz
Operating Shock 20 g 15 g 15 g 30 g
Nonoperating Shock 30 g 30 g 30 g 50 g
Dimensions (HxWxD), approx.
Base switch:
‡
147 x 152 x 112 mm
Expansion modules:
‡
147 x 97 x 112 mm
114 x 51 x 89 mm
4- and 5-port switch:
1
108 x 22.5 x 127 mm
7- and 8-port switch:
1
108 x 45 x 127 mm
132 x 56.7 x 35.6 mm
 Cat. nos.: Copper tap, 1783-ETAP. Fiber tap, 1783-ETAP1F, 1783-ETAP2F.
‡ Cat. nos.: Base switch, 1783-MS06T, 1783-MS10T, 1783-RMS06T, 1783-RMS10T. Expansion modules, 1783-MX08T, 1783-MX08F.
1 Cat. nos.: 4- and 5-port switch, 1783-US03T01F, 1783-US05T. 7- and 8-port switch, 1783-US06T01F, 1783-US08T.
Stratix 8000/8300: c-UL-us, CE, C-Tick, Ex, EtherNet/IP, Marine, IEC
61850, IEEE1613.
Stratix 6000: c-UL-us, CE, C-Tick, Ex, c-ETL-us, EtherNet/IP.
Stratix 2000: c-UL-us, CE, C-Tick, Ex.
EtherNet/IP Taps: c-UL-us, CE, C-Tick, Ex, EtherNet/IP.
When product is marked. See the Product Certification link at
www.ab.com for Declarations of Conformity, Certificates, and other
certification details.
Certifications
Environmental Specifications
