Ethernet Switches
Stratix 8000
9-8
Visit our website: www.ab.com/catalogs
Publication M117-CA001A-EN-P
Modular Managed Switches
General Quick Selection 9-Ethernet
Switches
Connection
Systems
PannelConnect Safety
Connection
6-Ethernet
Switches
Base Switches Expansion Modules
1783-MS06T 1783-MS10T 1783-MX08T 1783-MX08F
Ports per Module 6 10 8 8
Total Ports, Max
Up to 26
1
Copper Ports
4 10/100 ports
2 10/100/1000 ports
8 10/100 ports
2 10/100/1000 ports
8 10/100 ports
⎯
SFP Slots
2 (when SFP is used, corresponding 10/100/1000 copper is
disabled)
⎯
Fiber Ports
SFP slots support 100 Mbps and 1 G multi-mode and single-
mode fiber with LC connector
⎯
8 100 Base-FX ports with LC
connector
CompactFlash Memory
Yes (installed)
Spare replacement CompactFlash cards: 1783-MCF (for 1783-MS06T, 1783-MS10T)
Power Requirements 24/48V DC
Inrush Current, Max. 2.0 A
Power Dissipation 15.1 W 15.7 W 2.8 W 10.1 W
Fiber Optic Ethernet Data Rate —
⎯
100 Mbps
Fiber Optic Link Budget
⎯⎯
8 dB with 62.5 / 125 μm
multimode cable
4 dB with 50 / 125 μm
multimode cable
Fiber Optic Cable Length, Max —
⎯
Graded index multimode fiber;
2000 m
Fiber Optic Connector Type —
⎯
LC
1 Maximum port counts require expansion module.
Two dual-purpose ports can be used for SFP or 10/100/1000 copper.
Feature Benefit
Cisco IOS (Internetwork Operating System) Provides robust features compatible with the Cisco IT enterprise environment.
RSLogix 5000 AOP (Add On Profile) Enables easy switch setup and diagnostics with Logix controllers and the Integrated Architecture.
VLAN (Virtual LAN) with trunking Helps ease network management in the production network.
QoS (Quality of Service) Enables prioritization of applications, users, or data flows to help provide a higher level of network predictability.
Bandwidth Threshold Alarming Supports alarms to track network changes and detect malfunctioning devices.
STP/RSTP (Spanning Tree Protocol/Rapid
Spanning Tree Protocol)
Provides a resilient path between switches for applications that require a fault-tolerant network.
REP (Resilient Ethernet Protocol)
Supports ring, ring segment, or nested ring segments, providing network resiliency across switches with a rapid
recovery time.
MAC ID Port Security Enables tracking network changes from the controller through new MAC ID notifications.
DHCP per port
Supports assigning a specific IP address to each port, enabling device replacement without manually configuring IP
addresses.
SNMP (Simple Network Management
Protocol)
Provides familiar IT tools to monitor and configure network-attached devices.
CIP Sync (IEEE 1588)
Supports very high precision clock synchronization across automation devices for time-critical tasks such as
accurate alarming for post-event diagnostics and precision motion.
IEEE 802.1x Security Tracks access to network resources and helps secure the network infrastructure.
IGMP (Internet Group Management
Protocol) Snooping and Querier
Reduces multicast traffic from intensive IP applications, such as I/O control on EtherNet/IP.
EtherChannels Provides port trunking technology to automatically redistribute network traffic in the case of a failed link.
Smart ports
Recommended port configurations commonly used in automation network applications. Smart ports optimize a
port configuration to the type of device connected. They are easily assigned and help prevent port
misconfiguration.
Port Mirroring Copies network traffic seen on one switch port to another. Typically used as a diagnostic tool.
Key Software Features
Technical Specifications
