Alpine CDE-102 User Manual

27-EN
Connections
* When Subwoofer is OFF: Output is for Rear speakers. When Subwoofer is ON: Output is for Subwoofer.
For details on how to set the Subwoofer to ON/OFF, see “Subwoofer On and Off” on page 16.
Antenna
Blue
Blue/White
Orange ILLUMINATION
Black GND
Yellow BATTERY
Green
Green/Black
White/Black
Gray
Violet/Black
Violet
To iPhone/iPod
To power antenna
To amplifier
To the instrument cluster illumination
lead
Ignition Key
Battery
Speakers
Rear Left
Front Right
Rear Right
White
SPEAKER
RIGHT FRONT
SPEAKER
RIGHT REAR
SPEAKER
LEFT REAR
SPEAKER
LEFT FRONT
Front Left
REMOTE TURN-ON
Rear or
Subwoofers*
AUDIO INTERRUPT INPink/Black
Red IGNITION
Gray/Black
To vehicle phone
Amplifier
Amplifier
Front Left
Front Right
Speakers
POWER ANT
or
To Bluetooth INTERFACE (KCE-400BT)
(sold separately)

Alpine CDE-102 Specifications

General

Type	CD Receiver
Preamp Outputs	2-channel
Preamp Voltage	2V
Auxiliary Input	Yes
USB Input	Yes
Bluetooth	No
Built-in Bluetooth	No
Tuner	AM/FM
Display Type	LCD
Detachable Face	Yes
CD Player	Yes
Steering Wheel Control Ready	Yes
RMS Power Output	18W
Peak Power Output	50W
Playback Formats	CD, MP3, WMA
