45
10. Monitor Exploded View
No. Description
1BEZEL
2PANEL
3 MAIN BOARD
4POWER BOARD
5 U SB BOAR D( USB 9Q A1 )
6SHIELD
7 MAIN FRAME
8REAR COVER
9 U SB BOAR D( USB 8Q B3 )
10 HINGE RELEASE BUTTON
11 STAND_REAR
No. P/N De scriptio n
12 BASE S1 0M1G1730 6120 SC REW(MAIN BOARD TO MAIN FRAME)
13 HINGE S2 0M1G1730 6120 SCREW(POWER BOARD TO MAIN FRAME)
14 STAND_FRONT S3 0M1G1730 6120 SCREW(USB BOARD(USB9QA1) TO MAIN FRAME)
15 KEY BOARD S4 0M1G1730 6120 SCREW(USB BOARD (USB8QB3) TO MAIN FRAME)
16 KEY-GUIDE S5 Q01G6064 1 SCREW(HIN GE TO BASE)
17 3M DOUBLE FACE TAPE S6 0M1G 130 5120 SCREW(PANEL TO MAIN FRAME)
18 FOOT S7 0Q1G1040 8120 SCREW(HIN GE TO STAND_REAR)
