AOC 2230FH User Manual

22" LCD Color Monitor AOC 2230FH
4
1. Monitor Specification
Model number 2230Fh
Driving system TFT Color LCD
Viewable Image Size 558mm diagoanl
Pixel pitch 0.282mm(H) x 0.282mm(V)
Video R, G, B Analog lnterface & Digital Interface, HDMI
Separate Sync. H/V TTL
Display Color 16.7M Colors
LCD Panel
Dot Clock 165 MHz
Horizontal scan range 31 kHz - 83 kHz
Horizontal scan
Size(Maximum)
473.76mm
Vertical scan range 56 Hz - 76 Hz
Vertical scan Size(Maximum) 296.1mm
Optimal preset resolution 1680 x 1050 (60 Hz)
Highest preset resolution 1680 x 1050 (60 Hz)
Plug & Play VESA DDC2B/CI
Input Connector D-Sub & DVI-D,HDMI
Input Video Signal
Analog: 0.7Vp-p(standard), 75 OHM, Positive &
DVI-D,HDMI
Power Source 100~240VAC, 50/60Hz
Active < 49 W
Power Consumption
Standby < 2 W
Resolution
Speakers 2 x 2W
Connector Type 15-pin Mini D-Sub & 24 pin DVI-D, 19 pin HDMI
Signal Cable Type Detachable
Dimensions & Weight:
Height (with base)
416.8 mm
Width
510.2 mm
Depth
219.6 mm
Weight (monitor only)
5.2kg
Physical
Characteristics
Weight (with packaging)
6.7 kg
Temperature:
Operating 0° to 40°
Non-Operating -20°to 60°
Humidity:
Operating 10% to 85% (non-condensing)
Non-Operating 5% to 80% (non-condensing)
Altitude:
Operating 0~ 3000m (0~ 10000 ft )
Environmental
Non-Operating 0~ 5000m (0~ 15000 ft )
