19" LCD Color Monitor AOC 931Fwz
11
4.2 Power Supply Requirements
A/C Line voltage range 100 V ~ 240 V
A/C Line frequency range
50 ± 3Hz, 60 ± 3Hz
Current 1.5A max at 100V; 0.8A max at 240 V
Peak surge current < 55A peak at 240 VAC and cold starting
Leakage current < 3.5mA
Power line surge
No advance effects (no loss of information or defect)
With a maximum of 1 half-wave missing per second
DC output Voltage
5VDC ± 5％; 12VDC± 5％
CURRENT
1.5Amp (5V) ；2 Amp (12V)
4.3 Factory Preset Display Modes
Stand Resolution
Horizontal
Frequency(Khz)
Vertical
Frequency(Hz)
Dos-mode 720×400 31.47 70
VGA 640×480 31.47 60
VGA 640×480 37.5 75
SVGA 800×600 37.879 60
SVGA 800×600 46.875 75
XGA 1024×768 48.363 60
XGA 1024×768 56.476 70
XGA 1024×768 60.02 75
XGA 1024×768 48.78 60
XGA 1024×768 60.241 75
SXGA 1280×1024 64 60
SXGA 1280×1024 80 75
WXGA 1440×900 55.93 60
WXGA 1440×900 70.637 75
WSXGA 1680×1050 65.29 60
