AOC e2070Swn Service Manual

10
4.3.3 Electrical Characteristics
Parameter Symbol
Values
Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage V
LCD
4.5 5.0 5.5 Vdc
Permissive Power Input Ripple V
LCD
- - 0.3 V 3
Power Supply Input Current
I
LCD-MOSAIC
(60Hz) - 612 703 mA 1
I
LCD-BLACK
(60Hz) - 686 789 mA 2
I
LCD-BLACK
(75Hz) 760 874 mA
Power Consumption P
LCD
- 3.06 3.52 Watt 1
Inrush current I
RUSH
- - 3.0 A 1, 4
LED bar Electrical characteristics
Parameter Symbol Condition
Values
Unit Notes
Min. Typ. Max.
LED : 1
LED String Current Is - 105 110 mA 2
LED String Voltage Vs 34.2 36.6 39.0 V 3
Power Consumption PBar - 7.7 8.2 Watt 4
LED Life Time LED_LT 30,000 - - Hrs 5

AOC e2070Swn Specifications

General

Color	black
Tiltable	yes
OS Compatibility	windows
Screen Size	19.5 inches
Aspect Ratio	16:9
Resolution	1600 x 900
Native Resolution	1600 x 900
Refresh Rate	60hz
Horizontal Viewing Angle	90 degrees
Vertical Viewing Angle	65 degrees
Response Time	5 milliseconds
Brightness	200 candela per square meter
Contrast Ratio	20, 000, 000:1
Horizontal Scan Rate	83 kilohertz
Power Consumption	18 watts
Width with Stand	18.3 inches
Net Weight without Stand	5.0 pounds
