10 Monitor Exploded View
AOC-E960Swda
S3
S2
S1
13
12
11
10
9
8
1PCS
Main board
1PCS
Panel
1PCSMainframe
Power board
7
6
5
4
3
2
1
Back cover
Power lens
Keypad
1PCS
1PCS
1PCS
1PCS
1PCS
1PCS
Item
QUANTITY
PART NAME PART NUMBER
Q15G1119-***-***
Key board
4PCS
S4
3PCS
M3 Screw for PCB board
D1G1030-6-120
M1G1040-6-120
1PCS
Screw for stand & head
3PCS
Screw for hinge & stand
AM1G1740-8-225
3PCS
1PCS
Q33G0519-11-01A
1PCS
Rubber foot
Q12G6300-66-*
M4 Screw for ground
Bezel
Q34G7490-11-01A
Q33G0520-11-01A
Q34G7491-11-01A
Hinge
Q37G0249-***
1PCSStand
Q34G7498-11-01A
Base
Q34G7512-11-01A
AM1G1740-8-225
