AOC G4309VX/D User Manual

5
Other
If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a
Service Center.
Make sure that the ventilating openings are not blocked by a table or curtain.
Do not engage the LCD monitor in severe vibration or high impact conditions during operation.
Do not knock or drop the monitor during operation or transportation.
IThe power cords shall be safety approved. For Germany, it shall be H03VV-F, 3G, 0.75 mm2, or better. For other
countries, the suitable types shall be used accordingly.
IExcessive sound pressure from earphones and headphones can cause hearing loss. Adjustment of the equalizer to
maximum increases the earphones and headphones output voltage and therefore the sound pressure level.

AOC G4309VX/D Specifications

General

Panel type	VA
Screen shape	Flat
Display diagonal	43 \
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	- Hz
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	4000:1
Display number of colors	1.07 billion colors
Display brightness (typical)	720 cd/m²
HDMI	Yes
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.4
USB Type-A downstream ports quantity	4
Cable lock slot	-
Panel mounting interface	100 x 200 mm
Power consumption (standby)	- W
Power consumption (typical)	125 W
RMS rated power	7 W
Product color	Black
Market positioning	Gaming

Weight and Dimensions

Depth (with stand)	311.36 mm
Width (with stand)	977.3 mm
Height (with stand)	664.52 mm
Weight (with stand)	16900 g
Depth (without stand)	58.2 mm
Height (without stand)	567.35 mm
Weight (without stand)	14700 g
