19’’ LCD TV AOC L19W631
32
7. White Balance, Luminance Adjustment
Approximately 2 hour should be allowed for warm up before proceeding white balance adjustment.
Set the color analysis CA210. Please select channel 03 to adjust the white balance.
Color Temp. Cold Normal Warm
x 283 305 313
y 297 315 329
PC MODE
Y 200 200 210
x 283 305 313
y 297 315 329
AV MODE
Y 200 200 210
x 283 305 313
y 297 315 329
COMPONENT
（480i/480p）
Y 200 200 210
Note: Step of AV, COMPONENT480i, COMPONENT480p mode adjustment is the same as PC mode.
PC mode:
In the TV mode press MENU key, then press number key 100 Æ 9 Æ 9 Æ 9. It will achieve the
factory mode. The display as following:
1. Select source (PC/AV/YPbPr) to adjust the values.
2. Select “color temp" to adjust R, G, and B gain & bais values.
